APC SMT2200RMI2UNC APC Smart-UPS 2200VA uninterruptible power supply (UPS) Line-Interactive 2.2 kVA 1980 W 9 AC outlet(s)

APC
Availability :
Limited Availability
Mfr. Part# :
SMT2200RMI2UNC
CAD 4,435.46
Quantity :

PRODUCT DETAILS:

Stay always online and prevent data lossAs soon as the power fails, an APC Smart-UPS immediately supplies emergency power to all connected equipment. Because an APC UPS does this automatically, you prevent unwanted failure of, for example, a PC, server or switch. With the APC PowerChute Network Shutdown software, you can even have critical IT hardware shut down automatically and in a controlled manner when the UPS battery is almost empty. This prevents data loss, downtime and physical damage to hardware.SafetyIn addition, a Smart-UPS protects connected devices against peak voltage caused by lightning, among other things. This APC emergency power supply is ideally suited for (small) business use.Battery lifeYou can easily read the expected battery life in the runtime graph, which you can find between the product images. This makes it easy to see how long the UPS will supply emergency power at a certain load.Manage your Smart-UPSThanks to the pre-installed network card (ap9641), you can easily connect the APC UPS to the network. This allows you to monitor and manage the UPS remotely (SNMP) and the UPS can send a shutdown signal to multiple physical and/or virtual servers using PowerChute Network Shutdown software.PowerChute Network ShutdownPowerChute Network Shutdown is UPS management software that works with the UPS Network Management Card to protect Windows, Linux and Host ESXi, but also hyperconverged and virtual infrastructure*. In the event of a power failure, PowerChute can shut down your virtual machines correctly and the pre-configured boot sequence ensures that they are turned back on.*For HCI and virtual machine support an additional license is required:1 year: SWPCNS1Y-DIGI3 years: SWPCNS3Y-DIGI5 years: SWPCNS5Y-DIGIRemote management and monitoring of your networkThe network card can be managed remotely via the user-friendly web browser interface, remote management software EcoStruxure™ IT (SFTWES1-DIGI) or another SNMP-compatible system. Tip EcoStruxure™ IT also includes the functionalities of the support contract below.Support contractThe optional network card support contract license* ensures that you are always up-to-date and secure and includes additional benefits such as frequent updates with:• New and improved functions• Security updates• Advanced support(The functionality of the support contract is included free of charge in the first year of the UPS)*The above license and available in the variants:1 year: SWNMC3SU-1Y-DIGIUp to (Replace the bold number in the article number with the desired variant)6 years: SWNMC3SU-6Y-DIGIEase of useThe basic functionalities can be set and read using physical buttons and an LCD screen. Thanks to the included 4-post rail kit, you can easily mount the UPS in a rack.Extend the lifespanThe internal battery cartridge (RBC43) can be replaced easily, safely and independently by the user. This without having to switch off the APC SMT2200RMI2UNC or connected equipment. This way you can easily and cheaply extend the lifespan of the APC Smart-UPS and your equipment always stays online.Warranty extensionThe factory warranty of the SMT2200RMI2UNC is 3 years, with the exception of the battery cartridge, which has a factory warranty of 2 years. Both are extended by 3 years to 6 and 5 years respectively with the APC service pack (WBEXTWAR3YR-SP-04).Switched Outlet Groups: Remote reboot and phased start-upThanks to the Switched Outlet Groups it is possible to configure a phased/delayed power-on per UPS outlet group. This reduces the peak load on the UPS and brings it closer to the constant load, which can limit oversizing of the UPS.It is also possible to reset a group of multiple UPS outputs and the equipment connected to them. If SmartConnect Advanced (ERWPLUS1-1Y-DIGI), a UPS with SmartConnect port + Ecostruxure IT Expert (SFTWES1-DIGI) or a network card (ap9640) in combination with Ecostruxure IT Expert (SFTWES1-DIGI) are used, this can even be done remotely.This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. The 2200VA line interactive 2U rackmount UPS provides pure sine wave power to support critical electronics during power disruptions. It comes with IEC 320 C20 input, BS1363A British and Schuko CEE 7/EU1-16P input cables, 8x IEC 320 C13 and 1x IEC 320 C19 outlets, and 3x IEC jumper cables. It has a preinstalled Network Management Card for UPS network-based monitoring and management. The UPS comes with PowerChute Network Shutdown that provides graceful shutdown of physical servers, virtual machines, and HCI clusters. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. It provides surge protection against lightning strikes, power sags, brownouts and surges. The SMT UPS has a 3-year warranty, and the built-in lead-acid battery has a 2-year warranty. It is compatible with a dedicated user-replaceable battery, and the APC replacement battery cartridge helps restore UPS performance to the original specifications.

Power
Output power capacity2.2 kVA
Output power1980 W
Input operation voltage (min)151 V
Input operation voltage (max)302 V
Output operation voltage (min)220 V
Output operation voltage (max)240 V
Surge energy rating375 J
Emergency Power Off (EPO)O
Output frequency50/60 Hz
Input frequency50/60 Hz
Performance
UPS topologyLine-Interactive
Audible alarm modesBattery replacement
Response time4 ms
Surge protectionYes
WaveformSine
Auto-restartYes
Noise level55 dB
LED indicatorsYes
Audible alarm(s)Yes
Features
UPS topologyLine-Interactive
Output power capacity2.2 kVA
Web-based managementYes
Audible alarm modesBattery replacement
Response time4 ms
Output power1980 W
Input operation voltage (min)151 V
Input operation voltage (max)302 V
Output operation voltage (min)220 V
Output operation voltage (max)240 V
Surge energy rating375 J
Surge protectionYes
Emergency Power Off (EPO)O
WaveformSine
Output frequency50/60 Hz
Auto-restartYes
Noise level55 dB
Audible alarm(s)Yes
Input frequency50/60 Hz
Ports & interfaces
AC outlets quantity9 AC outlet(s)
AC outlet typesC20 coupler
Power plugC20 coupler
USB 2.0 ports quantity1
Ethernet LAN (RJ-45) ports1
Battery
Battery technologySealed Lead Acid (VRLA)
Battery recharge time5 h
Hot-swap batteryYes
Cold startYes
Battery capacity509 Ah
Automatic battery testYes
Design
Form factorRackmount
Rack capacity2U
Product colourBlack
CertificationCE, EAC, EN/IEC 62040-1, EN/IEC 62040-2, GS Mark, IRAM, RCM, VDE, WEEE
LED indicatorsYes
Display typeLCD
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 45 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 118110.2" (0 - 3000 m)
Non-operating altitude0 - 590551.2" (0 - 15000 m)
Technical details
Output voltage230 V
Output frequency50/60 Hz
Sustainability certificatesGreen Premium
Harmonized System (HS) code85078000
Total carbon footprint (kg of CO2e)3327.3
Compliance certificatesRoHS
Certificates
CertificationCE, EAC, EN/IEC 62040-1, EN/IEC 62040-2, GS Mark, IRAM, RCM, VDE, WEEE
Compliance certificatesRoHS
Management features
Web-based managementYes
Packaging content
Quick installation guideYes
Cables includedInput power cable, USB cable
Rack mount kitYes
Resource CDYes
Sustainability
Sustainability certificatesGreen Premium
Weight & dimensions
Width18.9" (480 mm)
Depth26.9" (683 mm)
Height3.39" (86 mm)
Weight93 lbs (42.2 kg)
Package width23.6" (600 mm)
Package depth38.6" (980 mm)
Package height10" (254 mm)
Package weight109.3 lbs (49.6 kg)
Packaging data
Quick installation guideYes
Cables includedInput power cable, USB cable
Resource CDYes
Rack mount kitYes
Package width23.6" (600 mm)
Package depth38.6" (980 mm)
Package height10" (254 mm)
Package weight109.3 lbs (49.6 kg)
Logistics data
Products per pallet8 pc(s)
Harmonized System (HS) code85078000
Total carbon footprint (kg of CO2e)3327.3
Other features
Output voltage230 V
