6NC9P - DELL - Available in Canada
6NC9P - DELL

DELL 6NC9P DELL S-Series S4148T-ON Managed L2/L3 10G Ethernet (100/1000/10000) 1U Black

DELL
Availability :
Limited Availability
Mfr. Part# :
6NC9P
CAD 19,654.00
Quantity :
Add to cart Add to cart
Get a Quote Get a Quote
Management features
Multicast supportYes
Switch layerL2/L3
Switch typeManaged
System event logYes
Quality of Service (QoS) supportYes
MIB supportSNMPv2, TCP, UDP, IP
Ports & interfaces
Copper ethernet cabling technology10GBASE-T
Switching optical modules type100 Gigabit Ethernet
Basic switching RJ-45 Ethernet ports quantity48
Basic switching RJ-45 Ethernet ports type10G Ethernet (100/1000/10000)
QSFP+ module slots quantity2
Console portRJ-45
USB 2.0 ports quantity1
Fiber optic connectorQSFP28
Power connectorAC-in jack
QSFP28 ports quantity4
Virtual LAN features
VLAN supportYes
Virtual LAN featuresTagged VLAN
Data transmission
Multicast MAC address table8000 entries
MAC address table272000 entries
Switching capacity1760 Gbit/s
Throughput1320 Mpps
Packet buffer memory12 MB
Optical fiber
Fiber optic connectorQSFP28
Switching optical modules type100 Gigabit Ethernet
Performance
StackableYes
Packet buffer memory12 MB
Minimum system requirementsLinux Kernel 3.16
Maximum cable length78.7" (2 m)
Internal memory4000 MB
Compatible operating systemsOS10
Built-in processorYes
Power
Power connectorAC-in jack
Power supply includedYes
AC input voltage100 - 250 V
AC input frequency50 - 60 Hz
Power consumption (typical)320 W
Power consumption (max)440 W
Redundant power supply (RPS) supportYes
Number of power supply units2
Input voltage250 V
Power cable length78.7" (2 m)
Power cable connector 1NBR14136
Power cable connector 2C13 coupler
Network
Networking standardsIEEE 802.1D, IEEE 802.1Q, IEEE 802.1Qaz, IEEE 802.1Qbb, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3ba, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Full duplexYes
Copper ethernet cabling technology10GBASE-T
VLAN supportYes
Port mirroringYes
Link aggregationYes
10G supportYes
Virtual LAN featuresTagged VLAN
IPv6 routes130
IPv4 routes200
Security
SSH/SSL supportYes
Security algorithmsIPSec
Access Control List (ACL)Yes
DHCP featuresDHCP relay, DHCP server
Multicast features
Multicast MAC address table8000 entries
Multicast supportYes
Protocols
Management protocolsCLI, SNMP, REST, API’s
Supported network protocolsIPv4 e IPv6 Roteamente Estático, RIP, OSPFv2 ,OSPFv3, BGP e IS-IS
Design
Rack mountingYes
StackableYes
Product colourBlack
Form factor1U
LED indicatorsYes
Number of fans4 fan(s)
Technical details
Compliance certificatesRoHS
System requirements
Minimum system requirementsLinux Kernel 3.16
Compatible operating systemsOS10
Power over Ethernet (PoE)
Power over Ethernet (PoE)No
Operational conditions
Operating temperature (T-T)5 - 40 °C
Storage temperature (T-T)-40 - 65 °C
Operating relative humidity (H-H)5 - 85%
Storage relative humidity (H-H)5 - 95%
Heat dissipation1500 BTU/h
Weight & dimensions
Width17" (431 mm)
Depth18" (457 mm)
Height1.73" (44 mm)
Packaging data
Rack mount kitYes
Other features
Input voltage250 V
Packaging content
Rack mount kitYes

Get a Quote

DELL 6NC9P DELL S-Series S4148T-ON Managed L2/L3 10G Ethernet (100/1000/10000) 1U Black
