Tripp Lite SU6000XFMR2UTAA Tripp Lite SU6000XFMR2UTAA isolation transformer

Tripp Lite

Availability :

Limited Availability

Mfr. Part# :

SU6000XFMR2UTAA

CAD 3,111.86 Save CAD 904.86237923437

CAD 2,207.00

Quantity :

PRODUCT DETAILS:

208V to 120V Isolation Transformer Converts High-Voltage Input to Low-Voltage OutputThe 6kVA 6kW SU6000XFMR2UTAA SmartOnline® Step-Down Isolation Transformer converts your UPS, utility or generator’s 208V or 240V high-voltage input to 120V low-voltage output. Set the input voltage using the front-panel switch. The transformer features eight NEMA 5-15/20R and four NEMA 5-15R outlets for connecting equipment with common NEMA 5-15P and NEMA 5-20P plugs. Resettable circuit breakers protect your low-voltage equipment against overload conditions. One NEMA L6-30R outlet supports high-voltage output.Supports Plug or Hardwire InputThe transformer’s four-foot power cord with 208/240V 24A input connects to a NEMA L6-30R outlet. You can also use the hardwire terminals to connect the transformer module to the power module’s input and output terminal blocks.Versatile Installation OptionsHardware is included for mounting the 208V to 120V isolation transformer transformer in 2U of space in an EIA-standard 19-inch 4-post rack with a maximum depth requirement of 27.25 inches. Use the optional 2POSTRMKITWM for 2-post rack mounting or the optional 2-9USTAND for mounting in an upright tower position (both accessories sold separately).TAA-Compliant UPS for GSA Schedule PurchasesThe SU6000XFMR2UTAA is compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases.2-Year Warranty and Environmentally Responsible DesignThe SU6000XFMR2UTAA comes with a 2-year warranty. It’s manufactured in compliance with strict RoHS specifications, reflecting Tripp Lite’s commitment to environmental responsibility.Typical Applications- Connecting low-voltage (120V) equipment to a high-voltage (208V or 240V) AC power sourcePackage Includes- SU6000XFMR2UTAA SmartOnline Step-Down Isolation Transformer- Rack-mounting hardware- Owner’s manual

Features
AC outlet types	Terminal
AC outlets quantity	240 AC outlet(s)
AC input voltage	208 V
AC input frequency	60 Hz
Rack mounting	Yes
Load capacity	6000 VA
Input current (max)	30 A
Housing colour	Black
Certification	TAA Compliant
Operational conditions
Operating relative humidity (H-H)	0 - 95%
Weight & dimensions
Width	17.5" (444.5 mm)
Depth	21.8" (552.7 mm)
Height	3.5" (88.9 mm)
Weight	72.5 lbs (32.9 kg)
Package width	22" (558.8 mm)
Package depth	27" (685.8 mm)
Package height	8.8" (223.5 mm)
Package weight	82.7 lbs (37.5 kg)
Technical details
Products per master (outer) case	1 pc(s)
Master (outer) case width	22" (558.8 mm)
Master (outer) case gross weight	82.7 lbs (37.5 kg)
Master (outer) case length	27" (685.8 mm)
Master (outer) case height	8.8" (223.5 mm)
Compliance certificates	RoHS
Logistics data
Country of origin	Taiwan
Products per master (outer) case	1 pc(s)
Master (outer) case width	22" (558.8 mm)
Master (outer) case gross weight	82.7 lbs (37.5 kg)
Master (outer) case length	27" (685.8 mm)
Master (outer) case height	8.8" (223.5 mm)
