Showing 110–120 of 184 results

HDMI A/V, Serial and IR Control Signals over Cat5/6 CablingReceives IP-based audio/video transmitted point-to-point from a source 328 ft. away Add low-cost network switches between transmitter and receiver to continue extending distance up to 328 ft. per switchDual HDMI outputs for connecting 2 displaysCreate a Multi-In, Multi-Out Installation Using B160-Series Transmitters and ReceiversConnect up to 64 transmitters and 255 receivers through multiple dedicated managed network switchesIGMP-enabled switches allow centralized control over which sources show on which displaysDisplays video from any analog or digital source, so you can mix and match technologies and use existing sources and monitorsEnhanced Technical FeaturesSupports video resolutions up to 1920 x 1080 (1080p) @ 60 HzUses H.264 video compression standardTransmits on 20–60 kHz IR frequencyExtends IR control signals that control a source from a remote displaySupports RS-232 serial baud rates up to 57600 BpsHDCP and 3D compatible when used with a DisplayPort or HDMI transmitterPlug-and-Play FunctionalityNo software or drivers requiredHardware included for mounting on wall, rack or poleCompatible with all B160-Series A/V over IP transmittersTAA-CompliantCompliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases

Tripp Lite's B165-101 RS232 Serial over Cat5 Extender Kit is a low cost solution that provides remote access and control of any RS232 protocol device. The B165-101 extends control of a serial device to over 1,000 meters ( 3280ft ). Supports full-duplex, 3 pin, data communication (signal ground, transmit data line, and receive data line).- Locates an RS-232 Serial device up to 304.8 m (1,000-ft.) from your system- Supports full-duplex, 3 pin, data communication (signal ground, transmit data line, and receive data line)- No software or drivers required...Plug-n-Play- Supported Baud Rates: 110, 1200, 9600, 38400, 57600, 115200 (max)

Tripp Lite High Speed Plug and Play USB 2.0 over Cat5 Extender Kit with 4-port hub, allows placement of USB hub up to 50 meters ( 164ft ) away from the source computer. Using solid conductor Cat5e rated cable, full 480mbps transmission speed is maintained the entire distance. Ideal for any situation where up to four USB devices need to be located more than the maximum 5 meter distance allowed by the USB timing signal. Also see B203-101-PNP for single device extension. For Solid Conductor patch cables, see tripp Lite N202- series patch cables.Key Features- Kit includes Transmitter and 4port Hub Receiver- Up to 50 meters ( 164ft ) distance over Solid Conductor Cat5e/Cat6 cable- Supports high speed data transfer rates up to 480mbps- Plug and Play...no Drivers or Software required- Backwards compatible to USB 1.1- Windows and MAC compatible- Compliant with the Federal Trade Agreements Act ( TAA ) for GSA Schedule purchases

The BHDBT-K-E3SI-ER HDBaseT HDMI over Cat5e/6/6a Extender Kit extends uncompressed HDMI audio and video, RS-232 serial and IR remote control signals up to 152.4 m (500-ft.) over a single Cat5e/6/6a cable, including a 1920 x 1080 (1080p) signal @ 60 Hz. In addition to HDMI, RS-232 and IR signals, this extender kit features three built-in 10/100 Ethernet ports on both the transmitter and receiver units. This allows connected devices, such as a Blu-ray™ player, cable/satellite box, and HDTV, to communicate with each other and access online content via LAN. You can also control RS-232 serial devices, such as touchscreen displays or scanners, at baud rates up to 115 Kbps. The two-way IR remote control feature (@ 39 KHz) lets you control your Blu-ray player using its remote when at the remote monitor or control your remote monitor using its remote when at the Blu-ray player. Locking HDMI ports (ideal for use with Tripp Lite’s P569-006-LOCK high-speed HDMI cables with locking connectors) on both the transmitter and receiver prevent cables from coming loose or undone, ensuring an intact signal. The plug-and-play BHDBT-K-E3SI-ER supports 7.1-channel surround sound, DTS-HD and Dolby TrueHD audio, as well as 3D video, EDID and HDCP.- Ideal for digital signs, classrooms and trade show booths- Built-in 10/100 Ethernet ports on transmitter and receiver- Extends a 1920 x 1080 (1080p) signal up to 152.4 m (500-ft.)- Supports 7.1-channel surround sound, DTS-HD and Dolby TrueHD- Controls RS-232 serial devices at baud rates up to 115 Kbps- Ideal for digital signage, classrooms, retail locations, conference rooms and trade show booths- Extends a high-definition 1920 x 1080 (1080p) @ 60 Hz signal up to 152.4 m (500-ft.)- Supports 7.1-channel surround sound, DTS-HD and Dolby TrueHD audio- Supports 3D video, EDID and HDCP- Reduces cable clutter and installation costs- Allows connected devices to communicate with each other and access online content via LAN- 2-way 39 KHz IR remote control functionality lets you control your Blu-ray player with its remote while standing at the remote monitor (and vice versa)- RS-232 serial port supports 115 Kbps full-duplex baud rates for scanners and touchscreen monitors- Plug and play with no software or drivers to download and install- Included mounting hardware for installing each unit on a wall, rack or pole- Prevent cables from coming loose or disconnected, ensuring an intact signal

The U344-001-HDDVI USB 3.2 Display Adapter enables the simultaneous connection of DVI and HDMI displays to a computer via a USB 3.2 port (a VGA monitor can be connected to the DVI-I port with an appropriate DVI to VGA adapter). Once the driver has been installed, the attached monitor(s) will be enabled immediately. The U344-001-HDDVI supports video resolutions up to 2048 x 1152 and video streaming up to 1080p. Up to three adapters can be connected to a single computer, allowing for up to six displays (see manual for minimum computer requirements). It supports USB 3.2 data transfer rates up to 5 Gbps, and is also backward compatible to USB 2.0. It is bus-powered from a computer's USB connection...no external power supply is required.

2-port transmitter and dual receivers extend an HDMI signal via Cat5e/6/6a cable to 2 projectors, monitors or TVs up to 100 ft. away. Recommended for digital signs, classrooms, churches, offices and retail settings.- Built-in Power over Cable (PoC) technology powers the receiver- Supports high-definition video resolutions up to 1080p (@ 60 Hz)- Supports 7.1-channel surround sound audio- HDCP and 3D compliant- Plug and play—no software or drivers to installThe B126-2P2M-POC 2-Port HDMI over Cat5/Cat6 Extender Kit includes a two-port transmitter and two low-profile receivers that work in tandem to extend an HDMI audio/video signal to two projectors, monitors or televisions. The kit is recommended for digital signs, trade shows, classrooms, churches, offices, retail settings and other applications where the source is located farther than conventional cables allow. HDMI cable (see Tripp Lite’s P568-Series) connects the audio/video source, such as a Blu-ray™ player, to the transmitter’s HDMI port. Cat5e/6/6a cable connects the transmitter to the receivers’ RJ45 ports (for best results, use 24 AWG solid-wire Cat6 cable, such as Tripp Lite’s N202-Series). The receivers plug directly into the displays’ HDMI input ports. Built-in PoC technology powers the receivers over Cat5e/6/6a cable, so no external power supply on the display side is needed.The B126-2P2M-POC can extend a high-definition 1080p (at 60 Hz) signal up to 50 feet and a 1080i signal up to 100 feet. In addition to crystal-clear video, the B126-2P2M-POC delivers full, rich audio up to 7.1-channel surround sound (multi-channel or PCM) and supports 3D and HDCP standards. Easy to set up with no software or drivers to install. Transmitter mounts to a wall, rack or pole using the included hardware. Complies with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases.Splits and Extends High-Definition HDMI Audio/Video Signals- 2-port transmitter extends HDMI A/V signal to 2 low-profile receivers- Recommended for digital signs, trade shows, classrooms, churches, offices, retail settings and other HDMI A/V applications- Extends a 1080p (@ 60 Hz) signal up to 50 ft. from source- Extends a 1080i signal up to 100 ft. from source- Supports 7.1-channel surround sound (multi-channel or PCM) audio- HDCP and 3D compliantEasy to Set Up and Use- Plug-and-play engineering—no software or drivers to download and install- Transmitter connects to source using HDMI cable, such as Tripp Lite’s P568-Series- Transmitter and receivers connect with Cat5e/6/6a cable (for best results, use Tripp Lite’s N202-Series)- LEDs indicate when units are receiving power or an HDMI signal- Mounting hardware included for installing transmitter on a wall, rack or poleTAA-CompliantComplies with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases

Transmits a 4K HDMI A/V Signal to 4 HDMI Displays SimultaneouslyRecommended for 4K digital signage in classrooms, churches, offices, restaurants, bars, trade shows, etc.Distributes A/V signals up to 15 ft. (4.6 m) when used with standard 28 AWG HDMI cableSupports UHD resolutions up to 4K @ 60 Hz for crystal-clear videoSupports HDCP 2.2 and EDID compliant to ensure compatibility with latest A/V hardwareCascade up to 3 levels of splitters together to increase the number of connected monitors up to 64Supports the Most Up-To-Date Features and FormatsSupports High Dynamic Range (HDR) for richer contrast and expanded color accuracyFull 3DDTS-HD, Dolby TrueHD, Dolby Digital Plus and LPCM 7.1-channel surround sound audio36-bit Deep Color (12 bits per channel)Video amplifier bandwidth of 600 MHz/6 Gbps per channel (18 Gbps total)Lip sync pass-through, xvYCC and x.vColorEasy to Use Almost AnywherePlug-and-play operation with no software required for easy, immediate installationSupports desktop use or wall-mounting using included hardwarePower supply includes international plug adapters (North America, Europe, U.K. and Australia)TAA-CompliantCompliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases

The B160-100-CSI RGB Component Video + Audio over IP Extender Receiver works with a B160-Series transmitter (sold separately) to extend and distribute component video + stereo audio, RS-232 serial and IR (infrared) remote signals from the source to the display located up to 328 feet (100 meters) away, which is more than 200 feet (61 meters) farther than a traditional Cat5e/6 solution. By adding a chain of low-cost unmanaged network switches, such as the NG5 (sold separately), you can continue extending the distance between source and display up to 328 feet per switch.Create a multi-in, multi-out installation with up to 64 transmitters and 255 receivers* by connecting dedicated managed Ethernet network switches** with Internet Group Management Protocol (IGMP), such as the NSS-G16D2 (sold separately). With a compatible B160-Series transmitter, this receiver works with any analog or digital source, including HDMI, VGA and DisplayPort, allowing you to mix and match technologies and use existing source devices. An IGMP-enabled switch will let you manage all connections for centralized control over which sources show on which displays.The B160-100-CSI supports video resolutions up to 1080i. It extends IR control signals that control a source, such as a Blu-ray player, from a remote display, as well as RS-232 signals at serial baud rates up to 57600 Bps. It mounts to a wall, rack or pole using the included hardware.*Unmanaged switch installations are limited to two transmitter units. Number of receivers is limited to number of ports remaining on unmanaged switch.**B160-Series designed for use with dedicated network switch. Connecting to a switch used with other networking equipment will result in degraded or non-functional performance.

Connect 3 HDMI Source Devices to an HDMI Display and Switch Between ThemThis 4K HDMI switch allows you to connect three HDMI source devices to one port on an HDMI display and switch back and forth between them. For instance, you can connect a Blu-ray player, cable/satellite DVR and video game system to one HDMI port on a monitor, projector or TV. Or you can connect three computers or media centers to an HDMI display for exhibiting digital signage or giving presentations. Hassle-Free Setup of 3 High-Definition Computers, Blu-Ray Players or Other SourcesThe B119-003-UHD is ideal for home entertainment systems, schools, point-of-sale displays, trade shows and anywhere else digital video is displayed. Connect up to three source devices to the HDMI input ports using HDMI cabling (sold separately), and plug the included external power supply into an AC power source. Another HDMI cable connects the HDMI output port to a monitor, projector or television. A red LED indicates the unit is receiving power, and blue LEDs indicate an HDMI signal is being received. Easy Switching of Audio/Video Source DevicesYou can switch from one source device to another in one of three ways: the Select button on the unit, the included remote control or RS-232 serial control. An RS-232 serial port connects a computer via DB9 cable (sold separately). Meets the Latest Audio/Video Standards, Including True 4K ResolutionsThe plug-and-play 3-port HDMI switch with remote control comes in a durable metal housing and requires no software or drivers. It meets current 3D, EDID and HDCP 2.2 standards to ensure you can use the switch with the most up-to-date Blu-ray players and other components. It supports Ultra High Definition (UHD) video resolutions up to true 4K at 60 Hz (4096 x 2160) and 36-bit True Color (12 bits per channel), as specified in HDMI 2.0, as well as 7.1-channel surround sound, DTS-HD, Dolby TrueHD, DSD (Direct Stream Digital) and HD (HBR) audio.

4-Port Multi-Format Presentation Switch Connects 4 Video Sources to One HDMI DisplayThis presentation switch connects four separate source devices to your 4K television, projector or monitor’s HDMI input and switches between them. The B320-4X1-MH features HDMI, DisplayPort, USB-C and VGA + Audio inputs for connecting Windows laptops, cable boxes, media servers, Blu-ray players, video game consoles and other video sources. Switch from one source to another using the manual push buttons, RS-232 commands or the included remote control.Suitable for a Wide Range of Audio/Video Applications for Work or PlayThis switch is recommended anywhere a variety of video signals is transmitted to a hi-def display. It is suitable for home theaters, video and multimedia presentations, security applications or digital signage in classrooms, bars, restaurants, conference rooms, lecture halls, exhibition centers and trade shows.Transmits Crystal-Clear True 4K Video with HDR, 4:4:4 Color and 7.1-Channel AudioThe HDMI, DisplayPort and USB-C ports support true 4K resolutions up to 4096 x 2160 at 60 Hz, as well as HDR video, providing a wide range of vibrant colors with richer contrast, brighter whites and deeper blacks that pop on your 4K display. HDCP 2.2 compliance allows you to stream 4K Amazon and Netflix content with no complications. This switch also supports 4:4:4 chroma subsampling for top-level PC gaming or using your HDTV as a PC monitor. Full, rich, uncompressed DTS-HD, Dolby TrueHD and 7.1-channel digital surround sound ensure your ears receive the same treat as your eyes. The VGA port supports HD video up to 1920 x 1080 (1080p) at 60 Hz.PD 3.0 Charging Port Charges the USB-C Source to Avoid Battery Drain and Signal LossThe USB-C Power Delivery port provides up to 20V 5A (100W), of which 90W is used to charge and power the connected USB-C device, such as a MacBook Pro or Windows laptop. Connect the device’s power supply or power adapter between the USB-C PD 3.0 port and an available AC outlet to prevent the source from running out of power prematurely.Plug-and-Play Operation for Quick Setup and Immediate UseThe switch works right out of the box with no software required. Mounting hardware is included for installing the switch on a wall, pole or 19-inch rack. Connect your devices to the switch’s ports with user-supplied cables (sold separately), and plug the switch’s external power supply into an AC power source.TAA-Compliant for GSA Schedule PurchasesThe B320-4X1-MH is compliant with the Federal Trade Agreements Act (TAA), which makes it eligible for GSA (General Services Administration) Schedule and other federal procurement contracts.
