PRODUCT DETAILS:
Power | |
---|---|
Output power capacity | 1 kVA |
Output power | 650 W |
Input operation voltage (min) | 100 V |
Input operation voltage (max) | 120 V |
Output operation voltage (min) | 100 V |
Output operation voltage (max) | 120 V |
Surge energy rating | 570 J |
Maximum current | 15 A |
Efficiency | 95% |
Output voltage regulation | 1% |
Input frequency | 50/60 Hz |
Performance | |
UPS topology | Line-Interactive |
LED indicators | Yes |
Audible alarm(s) | Yes |
Features | |
UPS topology | Line-Interactive |
Output power capacity | 1 kVA |
Country of origin | China |
Output power | 650 W |
Input operation voltage (min) | 100 V |
Input operation voltage (max) | 120 V |
Output operation voltage (min) | 100 V |
Output operation voltage (max) | 120 V |
Surge energy rating | 570 J |
Maximum current | 15 A |
Efficiency | 95% |
Output voltage regulation | 1% |
Audible alarm(s) | Yes |
Input frequency | 50/60 Hz |
Ports & interfaces | |
AC outlet types | NEMA 5-15R |
Power plug | NEMA 5-15R |
Emergency Power Off (EPO) connector | Yes |
Serial interface | Yes |
Battery | |
Typical backup time at half load | 14.4 min |
Typical backup time at full load | 5 min |
Hot-swap battery | Yes |
Cold start | Yes |
Automatic battery test | Yes |
Design | |
Form factor | Tower |
Country of origin | China |
Product colour | Black |
Certification | Meets FCC Part 15 Category B (EMI); ROHS (Restriction of Hazardous Substances); Tested to CSA (Canada); Tested to NOM (Mexico); Tested to UL1778 (USA) |
LED indicators | Yes |
Housing material | Plastic, Steel |
Operational conditions | |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -15 - 50 °C |
Operating relative humidity (H-H) | 5 - 95% |
Technical details | |
Compliance certificates | RoHS |
Weight & dimensions | |
Width | 6.75" (171.4 mm) |
Depth | 13.3" (336.6 mm) |
Height | 10.3" (260.4 mm) |
Weight | 35.5 lbs (16.1 kg) |
Package width | 9.7" (246.4 mm) |
Package depth | 18.3" (464.8 mm) |
Package height | 14" (355.6 mm) |
Package weight | 35.5 lbs (16.1 kg) |
Packaging data | |
Manual | Yes |
Package width | 9.7" (246.4 mm) |
Package depth | 18.3" (464.8 mm) |
Package height | 14" (355.6 mm) |
Package weight | 35.5 lbs (16.1 kg) |
Logistics data | |
Products per master (outer) case | 1 pc(s) |
Master (outer) case width | 9.7" (246.4 mm) |
Master (outer) case length | 18.3" (464.8 mm) |
Master (outer) case height | 14" (355.6 mm) |
Master (outer) case gross weight | 35.5 lbs (16.1 kg) |
Certificates | |
Certification | Meets FCC Part 15 Category B (EMI); ROHS (Restriction of Hazardous Substances); Tested to CSA (Canada); Tested to NOM (Mexico); Tested to UL1778 (USA) |
Packaging content | |
Manual | Yes |
$44.53
$84.82
Tripp Lite SMC1000T Tripp Lite SMC1000T uninterruptible power supply (UPS) Line-Interactive 1 kVA 650 W
MFR: Tripp Lite
Part #: SMC1000T
Qty: 1
