Tripp Lite SUINT1000XLCD Tripp Lite SUINT1000XLCD uninterruptible power supply (UPS) Double-conversion (Online) 1 kVA 900 W 4 AC outlet(s)

Availability :
Limited Availability
Mfr. Part# :
SUINT1000XLCD
CAD 1,055.22
Quantity :

PRODUCT DETAILS:

The SUINT1000XLCD SmartOnline® 230V 1kVA 900W On-Line Double-Conversion UPS provides battery backup and AC power protection against blackouts, brownouts, power surges and line noise that can damage electronics or destroy data. It converts AC input to DC power, and then converts DC to fully regulated sine wave AC output with +/-2% voltage regulation in online, double-conversion mode.Featuring four C13 outlets, the SUINT1000XLCD has an internal battery that provides 12.8 minutes of support at half load (450W) and 4.8 minutes at full load (900W). Adding external battery packs, such as BP24V15RT-2U (sold separately), provides extended runtime. Operating in optional economy mode reduces heat output and cooling requirements and consumes less electricity.An interactive front-panel LCD screen displays operating conditions and diagnostic data, such as load, voltage and battery levels. An audible alarm signals UPS startup, power failure, low battery, overload, UPS fault and remote shutdown conditions.EMI/RFI line noise filtering improves your equipment’s performance, and surge suppression prevents equipment and data damage from harmful power surges. With free downloadable PowerAlert® software, available via free download, SUINT1000XLCD enables safe unattended system shutdown and file saves in case of a prolonged power failure. A built-in card slot supports TLNETCARD, WEBCARDLX, SNMPWEBCARD, MODBUSCARD and RELAYIOCARD for network interface and remote monitoring and control.Protects Mission-Critical Rack-Mounted EquipmentProvides fully regulated sine wave AC output for small/medium servers, networking equipment and telecom systems+/-2% voltage regulation in online, double-conversion mode230V output voltageHigh 0.9 power factor offers 1000VA/900W output capacity4 C13 outletsSet of 2 C13/C14 jumpers included Reliable Battery Backup with Expandable RuntimeSupports half load for 12.8 min. and full load for 4.8 min.Zero transfer time suitable for advanced network applicationsExpandable runtime with optional external battery packs, such as BP24V15RT-2URestarts automatically after lengthy power outagesSNMP/Web CapabilityBuilt-in slot for SNMP network interface and relay card for remote monitoring and control optionsCompatible with TLNETCARD, WEBCARDLX, SNMPWEBCARD, MODBUSCARD and RELAYIOCARDOptional WEBCARDLX (sold separately) with the latest version of PowerAlert Device Manager firmware (PADM20) provides enhanced remote management capabilitiesPADM20 and PowerAlert Element Manager (PAEM) form a powerful tool for expanding maintenance functions in large installations, including firmware update checks and backup and restoration of device configurationsEMI/RFI Line Noise FilteringRemoves electromagnetic and radio frequency interference that can disrupt or damage equipment’s performanceInteractive LCD ScreenReports detailed status information, including load, voltage and battery levelsAudible AlarmIndicates startup/shutdown, power failure, low battery, overload and fault conditionsCommunications PortsUSB & Serial ports enable data-saving unattended shutdown when used with PowerAlert software, available via FREE download from tripplite.eaton.com/products/power-alert Optional Economy ModeEfficiently minimizes heat output, reduces cooling requirements and consumes less electricity

Power
Output power capacity1 kVA
Output power900 W
Input operation voltage (min)220 V
Input operation voltage (max)240 V
Output operation voltage (min)220 V
Output operation voltage (max)240 V
Surge energy rating425 J
Power factor0.9
Crest factor3:1
Battery
Battery typeBP24V15RT2U, BP24V28-2U, BP24V70-3U
Typical backup time at half load12.8 min
Typical backup time at full load4.8 min
Battery voltage24 V
Performance
UPS topologyDouble-conversion (Online)
Number of phases1
EMI/RFI noise filteringYes
Features
UPS topologyDouble-conversion (Online)
Output power capacity1 kVA
Country of originChina
Output power900 W
Input operation voltage (min)220 V
Input operation voltage (max)240 V
Output operation voltage (min)220 V
Output operation voltage (max)240 V
Surge energy rating425 J
EMI/RFI noise filteringYes
Power factor0.9
Crest factor3:1
Number of phases1
Ports & interfaces
AC outlets quantity4 AC outlet(s)
AC outlet typesC13 coupler
Power plugC14 coupler
USB portYes
Serial ports quantity1
Design
Form factorTower
Country of originChina
Product colourBlack
CertificationIEC 62040-1;2008+A1:2013; EN62040-2:2006; ESD:IEC61000-4-2:LEVEL 4, RS:IEC61000-4-3:LEVEL 3, EFT:IEC61000-4-4:LEVEL 2, SURGE: IEC61000-4-5:LEVEL 2, CS:IEC61000-4-6:LEVEL 3, CONDUCTED MAGNETIC FIELD: IEC61000-4-8:LEVEL 4
Housing materialSteel
Display typeLED
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 50 °C
Operating altitude0 - 39370.1" (0 - 1000 m)
Technical details
Compliance certificatesRoHS
Weight & dimensions
Width5.7" (144.8 mm)
Depth12.6" (320 mm)
Height8.9" (226.1 mm)
Weight21.3 lbs (9.66 kg)
Package width9.5" (241.3 mm)
Package depth17.6" (447 mm)
Package height13.4" (340.4 mm)
Package weight27.3 lbs (12.4 kg)
Packaging data
Package width9.5" (241.3 mm)
Package depth17.6" (447 mm)
Package height13.4" (340.4 mm)
Package weight27.3 lbs (12.4 kg)
Logistics data
Products per master (outer) case1 pc(s)
Master (outer) case width9.5" (241.3 mm)
Master (outer) case length17.6" (447 mm)
Master (outer) case height13.4" (340.4 mm)
Master (outer) case gross weight27.3 lbs (12.4 kg)
Certificates
CertificationIEC 62040-1;2008+A1:2013; EN62040-2:2006; ESD:IEC61000-4-2:LEVEL 4, RS:IEC61000-4-3:LEVEL 3, EFT:IEC61000-4-4:LEVEL 2, SURGE: IEC61000-4-5:LEVEL 2, CS:IEC61000-4-6:LEVEL 3, CONDUCTED MAGNETIC FIELD: IEC61000-4-8:LEVEL 4
Other features
Number of phases1
Battery typeBP24V15RT2U, BP24V28-2U, BP24V70-3U
